HSH-E lever block Characteristics:
The main parts of the HSH-E series lever block are made of high quality steel, it has the following features in design and use performance.
1. Safe, reliable and durable
2. High performance, easy to maintain
3. Small in volume, portable and light in weight
4. Small hand pull force and high efficiency
5. Advanced structure and beautiful appearance.
Model | HSH-E0.75T | HSH-E1.5T | HSHE3T | HSH-E6T | HSH-9T | |
Capacity(kg) | 750 | 1500 | 3000 | 6000 | 9000 | |
Standard Lifting Height (m) | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | |
Testing Load(kg) | 1125 | 2500 | 4500 | 7500 | 11250 | |
Force For Full Load(n) | 250 | 310 | 410 | 420 | 420 | |
Load Chain | Falls | 1 | 1 | 2 | 3 | 4 |
Dia*Pitch | 6*18 | 8*24 | 10*30 | 10*30 | 10*30 | |
Hmin Headroom | H mm | 440 | 550 | 650 | 650 | 780 |
Handle Length (mm) | 285 | 410 | 410 | 410 | 410 | |
N.W/G.W(kg) | 6.7 | 11 | 17.5 | 25.5 | 49.8 | |
Demension(mm) | A | 155 | 190 | 200 | 200 | 210 |
B | 120 | 140 | 150 | 150 | 150 | |
C | 130 | 150 | 200 | 220 | 340 | |
D | 37 | 45 | 55 | 65 | 75 | |
E | 35 | 42 | 42 | 45 | 68 | |
Additional weight per 1M lift |
